WDT Computer Control  Spring Testing Machine






Application and working Principle

This machine is a new generation of Computer Control Spring Testing Machine, specially designed for tension spring, compression spring,saucer reed ETC.     The full-digital controller in the computer system controls the motion of servo motor though speed control system,through deceleration system, the precision ball screw pair drives the movable cross-beam to move down, to finish compression and tensile test of spring.

Technical specification



Model/parameter WDT-10/20/50/100 WDT-200/300/600
Max. Test force 10kN/20kN/50kN/100kN
       ( 1Ton-10Ton )
200kN/300kN/600kN
    ( 20Ton-60Ton )
Measurement range of test force               0.4%-100% ( can be customized )
Indicating accuracy of test force             Superior to ± 1% of indicating value
                      ( can be customized )
Resolution of displacement                         0.001mm

Test speed range       0.01-500mm/min
   (can be customized)
   0.01-300mm/min
   0.01-200MM/min
 (can be customized)
Effective testing space 600mm  ( can be customized )
Structure of host Four-column double spaces
Weight 500KG/600KG 1500KG
Power supply  1- phase, 220V, 50Hz ( can be customized )
